Development of
an improved hydrocephalus shunt

CSF-Dynamics is developing a new type of hydrocephalus shunt that overcomes the major issues of current shunts on the market. The shunt is currently undergoing clinical testing. CSF-Dynamics expects the shunt to be approved for clinical use by end 2027.

CSF-Dynamics received a Horizon 2020 Phase 2 SME grant (849502) from the European Commission to support our First in Human trial. We are now planning a larger Pivotal Study in 5 countries.

Please contact us by email if you are interested to know more about the technology and the status of the development.


News: JNS article

After several years of research and technological development at CSF-Dynamics we can now present the results of the pilot study on our novel CSF-shunting device.  This method of shunting to the intracranial sinus for the treatment of hydrocephalus is intended to significantly reduce both revisions and complications by mimicking physiological drainage. We would like to thank Dr Sune Munthe and his team at Odense University Hospital for supporting us in this First in Human investigation and showing that our outlet remains patent and avoids overdrainage. We are convinced that this method has a future in the standard of care and will move forwards to plan a larger study as soon as possible.



The abstract can be found on the Journal of Neurosurgery.

#EANS2022, Belgrade

Sune Munthe MD, PhD, neurosugeon, Odense University Hospital, Denmark presented the promissing final results of the First-in-Human clinical study at the European neurosurgical congress at Crowne Plaza Belgrade, Serbia.

Results will be published in a peer reviewed journal beginning 2023.


#Hydrocephalus2022

Sune Munthe MD, PhD, neurosugeon, Odense University Hospital, Denmark presented the very promissing final results of the First-in-Human clinical study at the fourteenth meeting of the Hydrocephalus Society in Gothenburg, Sweden, 10 September 2022.

Results will be published very soon in a peer reviewed journal.

Please feel free to contact Tom Markussen (Chief Innovation Officer) or Svend Erik Børgesen, MD (Chief Clinical Officer, CSF-Dynamics) if you are interested tp get more information about the technology and the clinical trials.

#SNS2022, Bergen

The preliminary results of the First-in-Human clinical study was presented at annual meeting of Scandinavian Neurosurgical Society (SNS) by Sune Munthe MD, PhD, neurosugeon, Odense University Hospital, Denmark, on Sunday 15 May 2022 at Radisson Blu, Bergen, Norway.

Svend Erik Børgesen, MD (Chief Clinical Officer, CSF-Dynamics) was also present at the session to answer the questions and comments from the audience.

SNS logo.png
AANS_2022_OG_Image_1200x628_2 (1).png

#AANS2022, USA

The first preliminary results of the First-in-Human clinical study was presented at AANS by Mikkel Andersen MD, Odense University Hospital, Denmark, 2 May 2022 at AANS, Pennsylvania Convention Center.


Present day shunts cannot deliver normal physiological flow

Since the invention and introduction of cerebral shunts in the 1950s, the two most important innovations have been the addition of an anti-gravitational valve plus a feature to adjust the valve setting magnetically. Despite these innovations the clinical outcome has not improved in any significant way, and shunts continue to have an unacceptable tendency to malfunction with revisions still commonplace (30% within 6 months). Moreover, shunts fail to provide normal and controlled drainage of CSF because the drainage profile of a shunt is very different from physiological drainage. With current shunts, too much or too little CSF can be drained depending on factors such as body position or the inconstant pressure within the absorption site (heart or abdomen). This lack of synchronisation can result in large variations in intracranial pressure preventing the patient from leading a normal life.


Shunt low2 w text 2.png

SinuShunt: Following the principle of physiological drainage

The SinuShunt mimics normal physiological absorption of CSF by draining into the intracranial sinus vein. There are three important advantages: (i) the differential pressure variation between the ventricles and the absorption site is minimised, (ii) the detrimental siphon effect is eliminated, and (iii) the unfavourable peritoneal cavity is avoided as a drainage site. The SinuShunt can therefore operate independently of any arbitrary physical forces which can affect standard VP (as well as VA) shunts.

Shunting to the sinus vein is an obvious solution since it mimics normal CSF drainage. Different researchers have recognised this and have tested the concept over recent decades, but all concluded that despite the patient experiencing clinical benefit, a shunt outlet could not last in the intracranial sinus vein, and that it would eventually become enveloped in endothelium, usually within 3 months.



Based on our own comprehensive clinical experiences with the first generation SinuShunt (tested on 110 patients), we have now developed a new generation of the device to overcome this technical shortfall of the outlet becoming overgrown.  The new SinuShunt is designed to keep the outlet in the middle of the vein, preventing contact with the wall of the vein and ensuring the CSF flows unhindered.

First-in-Human and pivotal clinical studies

Odense University Hospital in Denmark has been conducting the First in Human clinical study with 12 patients (2020-2022), led by neurosurgeon Dr Sune Munthe. The purpose of the study has been to demonstrate that the SinuShunt outlet will stay patent for at least 6 months. The study will conclude in August 2022 with no failures reported as of April 2022.

Based on these very positive results we are currently preparing the pivotal study (86 patients) which will be conducted across at least 4 clinical sites in four countries. This study will provide the necessary data for future FDA approval (US market) and CE marking (European market).


About CSF-Dynamics

CSF-Dynamics was founded in 1996 by Svend Erik Børgesen, Dr. Med. Sci., former chief neurosurgeon at the Danish National Hospital in Copenhagen, specialist in hydrocephalus, recipient of the Medtronic Pudenz Prize and recognised by the Queen of Denmark for neurosurgical services. After operating more than 500 hydrocephalus patients (as well as many other operations), he invented the SinuShunt™ as a response to the need for a radically better hydrocephalus shunt which would continue to work on a long-term basis.

Initial results from his research conducted 2001-2003 showed that shunting to the intracranial venous sinus reduced overdrainage and demonstrated clinical benefit but would require additional design changes to prevent endothelium overgrowth of the outlet. Post-retirement, Dr Børgesen partnered with the Danish engineering consultancy 2C ENGINEERING in 2017 to redesign the outlet, leading to our pilot study from 2020 to 2022.  So far, data collected is extremely promising with the outlet remaining open for over 6 months indicating better-than-average shunt survival and confirming that shunting to the dural venous sinus provides a safe, simple and long-lasting solution.
